Renon Power · High-Voltage Stacked Battery

Renon Power Xtreme HV 1.0

High-voltage stacked home battery — 9.6 to 19.2 kWh, hybrid-inverter ready.

The Renon Power Xtreme HV 1.0 is a high-voltage stacked LiFePO4 home battery that scales from 9.6 kWh (2 modules) to 19.2 kWh (4 modules), with a nominal voltage of 192–384 V for compatibility with high-voltage hybrid inverters. Its modular stack design adapts to a range of home energy needs, with real-time monitoring and integrated fire-prevention safety systems.

Key features

• High-voltage stacked design (192–384 V)
• 9.6 / 14.4 / 19.2 kWh (2–4 modules, 4.8 kWh each)
• LiFePO4 with real-time monitoring & fire prevention
• Compatible with high-voltage hybrid inverters
• Modular — scale by stacking modules

Specifications

Configuration

High-voltage stacked (4.8 kWh/module)

Capacity

9.6 – 19.2 kWh (2–4 modules)

Nominal Voltage

192 / 288 / 384 V

Chemistry

LiFePO4

Certifications

IEC 62619, UN 38.3, CEI 0-21, EN 62477, MSDS

Specifications shown for reference. Lumis will confirm final scope and configuration during system design.
